Gravity Positive displacement Oval Gear Mechanical Flowmeter

FOB Reference Price:Get Latest Price
US $500-6,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Liaoning, China (Mainland)
Brand Name:
Metery
Model Number:
MT100OG
Sort:
Gravity Positive displacement Oval Gear Mechanical Flowmeter
Caliber:
DN10-DN200
Brand name:
Metery
Display:
Mechanical or Electrical digital
Flow range:
0.1-360 m3/h
Material:
cast iron, 301, 316 steel
web:
www.meterytech.com
Supply Ability
Supply Ability:
100 Set/Sets per Day
Packaging & Delivery
Packaging Details
carton in container of Gravity Positive displacement Oval Gear Mechanical Flowmeter
Port
Dalian
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(day) 5 To be negotiated






Technical parameters of Gravity Positive displacement Oval Gear Mechanical Flowmeter

Inside nominal diameter (mm)

8~250

Accuracy

0.2%,0.5%

Pressure loss

0~1000Mpas<80kpa

Wirking pressure

1.6,2.5,4.0,6.3,10,16,25,42MPa

Temperature range

-20°C~+300°C

Dielectric viscosity

0.1~1000Mpas

Environment condition

The temperature of -20 °C ~ +50 °C moisture ≤ 85%, pressure 86kpa ~ 106kpa

Connection flange

GB, the other can according to user specified flange standard

Anti-hazard classification

Intrinsic safety type laII CT4, explosion suppression dII BT4





Product Details of Gravity Positive displacement Oval Gear Mechanical Flowmeter













Display Head







Flow range

Inside nominal diameter (mm)

Flow range  m3/h

Accuracy class 0.5

Accuracy class 0.2

8

0.05~0.5

0.1~0.3

10

0.1~0.6

0.2~0.6

15

0.16~1.6

0.5~1.5

20

0.25~2.5

0.8~2.4

25

0.6~6.0

2~6

40

1.6~16

5~15

50

2.5~20

6~18

80

6~48

12~48

100

8~80

20~60

150

25~200

60~180

200

45~360

100~300

250

80~500

150~450

Note: Can be custom-made non-standard flow meter



Overall dimensions for installation

Type and nominal

diameter(mm)

Flange spacing-L

Total height-

H

Center height- M

Material quality

Pressure rating -MPA

Installation

MT 8

180

260

35

carbon steel

304

316

1.6

2.5

4.0

6.3

10

26

42

horizontal type

MT 10

180

260

50

MT 15

180

260

60

MT 20

240

300

100

MT 25

240

300

100

MT 40

280

350

150

MT 50

280

350

150

MT 80

400

500

250

MT 100

400(560)

600

300

MT 150

650(700)

700

350

1.6

2.5

4.0

6.3

MT 200

1000(800)

700

350

MT 250

1000

800

400



Structure and working diagram



Detailed Mechanical Principle









Installation Diagram





Workshop and parts

  We have our own factories and workshop to ensure the quanlity and delivery, so as the reputation related to our

long run development. Q&C team will make our product enough warranty and credit for our domestic and aboard users
