Battery GSM SMS Electromagnetic flowmeter flow meter

FOB Reference Price:Get Latest Price
US $300-2,000 / Sets | 1 Set/Sets (Min. Order)
Material:
carbon steel
Accuracy:
0.5%
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Liaoning, China (Mainland)
Brand Name:
Metery
Model Number:
MT100E
Product Name:
Battery GSM SMS Electromagnetic flowmeter flow meter
Accuracy:
± 0.20% of reading plus zero stability
Repeatability:
± 0.1%
Max Fluid Velocity:
10 m/s
Flow Range:
0.028 to 336,650 GPM (0.0064 to 76,453 m3/h)
Line Sizes:
1 to 16 inches
Housing Material:
Acrylic painted carbon steel, optional stainless steel
Electrode Material:
Hastelloy C22 / Platinum / Titanium / Tantalum
web:
www.meterytech.com
Supply Ability
Supply Ability:
100 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
Packaging of Battery GSM SMS Electromagnetic flowmeter flow meter
Port
Dalian
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(day) 6 To be negotiated

Email:  info(at)metery-tech.com,  sales(at)meterytech.com
-----------------------------------------------------------

                          www.meterytech.com





MT100E Battery GSM SMS Electromagnetic flowmeter flow meter









 Working Principle





Receiving Software



Host PC setting





Workshop and Warehouse









Product Description
                                                           Electromagnetic water liquid  flow meter

Item

Compact type

Remote type



Flange connection

Inserted type

Threaded connection

Flange connection

Inserted type

Threaded connection

Caliber(mm)

15~3000

125~3000

10~25

15~3000

125~3000

10~25

Pressure(MPa)

0.6,1.0,1.6,4.0

Accuracy

±0.5%, ±0.3%(±0.2% available for special order)

Applicable medium

Conductive liquid and slurry

Medium Temperature

≤150°C

Medium Conductivity

≥5μS/cm

Medium Velocity

≤15 m/s

Ambient

Temperature:-25°C~+60°C, Humidity: 5%~90%

Liner Material

DN10mm~32mm: Polytetrafluoroethylene(F4), Polyurethane;
DN40mm~1000mm: F4, Polyurethane, Polychloropree rubber;
DN1000mm~3000mm: Polychloropree rubber;
Others: Polyvinyl fluoride, Fluorinated ethylene-propylene(FEP), etc.

Electrode Material

Mo-containing stainless steel, Hastelloy B, Hastelloy C, Titanium alloy, Tantalum alloy, Platinum-iridium alloy, Stainless steel-coated tungsten carbide

Electrode Type

Fixed type(DN150~DN2600); Blade type(DN300~DN1600)

Flange Material

SS, CS

Communication

RS485, RS232, HART, Modbus, Profibus-DP

Signal Output

Analog 4-20mA, isolated, load resistor≤750Ω

Power Supply

AC 85-265V, 45-63Hz, power≤20W;
DC 11-40V; lithium battery(3.6V)

AC 85-265V, 45-63Hz, power≤20W;
DC 11-40V

Display

LCD display with back light.

Intelligent flow totalizer display.

Protection Grade

IP65

IP65, IP67, IP68

Explosion-
proof Grade

ExdmCT4, mdBT4

non





Workshop and Inspection Room Views



Installation Field



Packing Meters Waiting for Shippment


Our Services
1.We have aquired ISO, CE,TUV and BQC and other International Certificate;
2.Our flowmeter obtain the APPEARANCE DESIGN PATENT, UTILITITY MODEL PATENT ETC which can distinguish our flowmeter from other suppliers;
3.We have our own QUALITY CONTROL SYSTEM, domestic unique largest-diameter calibration equipment checking ability from DN10 to DN2000; 0-10cubic and 0-65cubic Volumetric Standard;
4. Has 30 years research & development capability; 20 years focus on flow instruments; 10 years professional engineers and technicians;
5.Our production line capacity can reach: 600sets/month electromagnetic flowmeter, 600sets/month vortex flowmeter, 500sets/month throttling device flowmeter which can fully satisfy our customer’s needs;
6.We have good relationship and agreement with many EXPRESS FORWARDERS, shipping company like MAERSK, COSCO, OOCL, APL ETC, that’s why we can get lower AIR FREIGHT & ocean freight to help you save the costs and win the market;
7. There are 12 months warranty of our products from the date of original delivery, "three guarantees" service (return, replacement, warranty);
8.Your OEM orders are welcomed. Customer's logo is available.
